Blossom HVAC
UP TO 1500SQF AROMA COVERAGE
Experience the perfect blend of style and functionality with the Bloom Blossom Aromatherapy HVAC Ready Cold Air Home & Office. This sleek and compact diffuser offers plug and play portability, allowing you to effortlessly infuse your entire home or building with delightful scents. With advanced atomization technology & HVAC system connectivity it ensures residue-free diffusion and covers up to 1500 square feet of space. Safe for pets and children, this waterless and heatless diffuser is your key to creating a serene and fragrant environment. Elevate your surroundings with the Bloom Aromatherapy Diffuser and indulge in the transformative power of scents.
Why choose Blossom HVAC?
Blossom HVAC Features
- Waterless Diffusion
- 200ml Oil Reservoir
- Secure Oil Locking
- Intelligent Touch
- On/Off Programmable
- 1500sqf+ Coverage
- Can be used without HVAC System
- HVAC Ready
- Wall Mountable
- LED Oil Indicator
Business
1500SQF AROMA COVERAGE
Car Dealership
Hotel Lobbies
1500SQF AROMA COVERAGE
Spa / Salon
Condo or Townhouse
1500SQF AROMA COVERAGE
Retail
Club / Bar
1500SQF AROMA COVERAGE
Spa / Salon
BLOSSOM HVAC
up to 1500SQF Coverage
HVAC READY
Mounts directly on HVAC System in 10 minutes!
System Requirements:
- 100 - 240V Outlet
- 12V Output
- Central Air System
- 24/7 Running System Fan
- Drill
- Tube & Mounting Screws Included.
Blossom HVAC Diffuser Setup
Step One: Initial Setup
- Remove Blossom HVAC waterless diffuser from the box.
- Locate (2) small plastic bags containing: 2X Keys to unlock oil compartment, 1X Atomizer Replacement Head, HVAC tube adapter, 3X Screws, 3X Drywall Plugs.
- HVAC INSTALL / WALL MOUNT: Find location you want to mount diffuser either directly on ducting, or wall in proximity to the power source. Using a drill screw in provided mounting screws, and mount unit.
- Remove top diffuser dispersion nozzle adapter and replace with provided HVAC tube adapter nozzle.
- Make sure the “fan” ON/OFF Switch located on the left side of the machine in in the “ON” (Down Position) at all times when machine is in use. (This pushes the diffused oil out and away from machine into the HVAC System.)
Step Two: Programming Diffuser
SETTING THE CLOCK (24Hr) LOCAL TIME
- Click “SET” Now select the local time current “HOUR” using the UP/DOWN buttons. (Example: 6pm = 18:00) Hit “SET” to confirm “HOUR”
- Now using the UP/DOWN buttons select the “MINUTES” and hit “SET” when complete.
- Using UP/DOWN buttons now select the current day of week then hit “SET” to confirm selection.
SET OIL VOLUME
- Now Set the “VOLUME OF OIL” to be used in diffuser. If using provided 200ml bottle set at default (200ml) setting. If using a Bloom Aromatherapy 120ml Oil Bottle set at (120ML) Using the UP/DOWN button select the total oil “VOLUME” then hit “SET” to confirm, Now using UP/DOWN buttons select ML oil amount in bottle and hit “SET” to confirm. Now set the ML/Per Hour (Leave at the Default setting) hit “SET”
- THE MACHINE IS SET
SET AUTO ON/OFF TIME & SCENT INTENSITY
- Click “MODE” and then Click “SET” and use the “UP/DOWN” buttons to select the “HOUR” Diffuser will “TURN ON” at and begin diffusing. (Example: Turn on at 7am = 07:00) Click “SET” when hour is confirmed.
- Now using the UP/DOWN buttons select the Diffuser on “MINUTES” hit “SET”
- Now using the UP/DOWN buttons select the days of week you wish the diffuser to turn on. Cycle through Monday, Tuesday, Wednesday, Thursday, Friday, Saturday, Sunday at top of LCD screen clicking “OK” button with tiny triangle selecting the days desired then click “MODE” when confirmed.
- Now use the “UP/DOWN” buttons to select the “HOUR” Diffuser will “TURN OFF” at and stop diffusing. (Example: Turn Off at 8pm = 20:00) Click “SET” when hour is confirmed.
- Now using the UP/DOWN buttons select the Diffuser OFF “MINUTES” when minutes confirmed hit “MODE”
- Now using the UP/DOWN buttons select the total seconds aroma will be emitted for. (the longer the seconds the stronger the scent) when confirmed hit “MODE”
- Now using the UP/DOWN buttons select the total “PAUSE” seconds aroma will be stop emitting, cycling back and forth from On and Pause. (the longer the seconds the weaker the scent) when confirmed hit “MODE”
- Click “MODE” 5X to confirm setting and return to the main screen!
- THE MACHINE IS NOW SET AND PROGRAMMED
IF SEE A RED LIGHT or OIL IS BEING REPLACED
- Hold the “MODE” button down for “6” Seconds to reset oil to full. (Light will go back to “GREEN”)
Step Three: Cleaning & Replacing Oil
- Locate Oil Reservoir and remove from diffuser.
- Using provided bottle that came with unit add 100% Rubbing Alcohol or ISO propanol.
- Screw bottle with 100% ISO or Alcohol back onto diffuser and run the machine for 60 – 120 seconds.
- Remove bottle from diffuser and screw in new bottle of Bloom Aromatherapy or Saku Aromatherapy Essential Aroma Diffuser oil.
Bluetooth / Wifi Setup
- Coming Soon.
Blossom HVAC
up to 1500sqf | Residential | Commercial
This sleek and compact diffuser offers plug and play portability, allowing you to effortlessly infuse your entire home or building with delightful scents. With advanced atomization technology & HVAC system connectivity it ensures residue-free diffusion and covers up to 1500 square feet of space. Safe for pets and children, this waterless and heatless diffuser is your key to creating a serene and fragrant environment.
BlossomPRO+
up to 3600sqf | Residential | Commercial
This sleek and mid sized HVAC diffuser offers plug and play portability, allowing you to effortlessly infuse your entire home or building with delightful scents. With advanced atomization technology & HVAC system connectivity it ensures residue-free diffusion and covers up to 3600 square feet of space. Safe for pets and children, this waterless and heatless diffuser is your key to creating a serene and fragrant environment.
SumoPRO+
up to 10,000sqf | Residential | Commercial
The SumoPRO+ HVAC Waterless Large Area Commercial Scent Diffuser has been designed to hold large volumes of pure undiluted essential oil in its 2000ml reservoir. Utilizing the latest in aroma technology the SUMOPRO+ HVAC is Wifi enabled and can be fully controlled remotely via mobile APP.
SumoDUAL+
up to 25,000sqf | Residential | Commercial
The SumoDUAL HVAC+ commercial cold air scent diffuser system covers a huge 25,000+ sqf area combined with (2) large 2 Litre oil reservoirs. This system has dual programable computers allowing for two different scents to dispense at set times. Imagine a energizing citrus scent during the day that automatically switches to a relaxing lavender in the evening.
